High-Speed Double-Sheet Folding & Gluing Machine (Multi-Station). Engineered for large-scale double-sheet carton production, featuring extended format handling and high multi-station productivity.
GET A QUOTE
The LY-3500 delivers the extended format capacity required for large-scale two-sheet carton manufacturing. Its spacious design accommodates bigger substrates, while the multi-station layout maintains efficient workflow. A solid choice for manufacturers scaling up to handle consistently larger box dimensions.
| Model | LY-3500 |
| Max. Feeding Paper Size (Single Sheet) | 1750×1700mm |
| Min. Feeding Paper Size (Single Sheet) | 350×200mm |
| Max. Height of Paper Stack | 450mm |
| Main Motor Power | 3kw |
| Total Power | 12.5kw |
| Total Weight | 6t |
| Machine Dimensions | 11000×4500×1600mm |
| NO. | Name | Picture | Brand |
|---|---|---|---|
| 1 | Bearing |  |
NSK, Harbin |
| 2 | Linear Guide Rail |  |
HIWIN |
| 3 | PLC |  |
Delta |
| 4 | HMI |  |
WECON |
| 5 | Relay |  |
OMRON |
| 6 | Contactor | |
Schneider |
| 7 | Frequency Converter |  |
SINEE |
| 8 | Belt | |
Shenzhen |
| 9 | Cylinder, Solenoid Valve |  |
TAIWAN AirTAC |
| 10 | Optoelectronic Switch | |
Schneider |
| 11 | Main Motor |  |
MAILI |
| 12 | Adjusting Motor | |
MAILI |
| 13 | Servo Motor |  |
SINEE |
| 14 | Machine Head Belt |  |
Cowhide Band |
| 15 | Conveyor |  |
Shenzhen |
Yes. The LY-3500 is designed with multi-station flexibility and can be configured to handle custom and irregular box shapes with appropriate adjustments to the feeding, folding, and splicing sections.
The multi-station layout allows operators to work simultaneously on different stages of the gluing process—such as feeding, gluing, and stacking—which streamlines workflow and increases overall throughput. It is especially beneficial for operations handling a mix of box sizes or custom orders.
While the LY-3500 is a semi-automatic machine, its adjustable stations and straightforward controls allow for efficient changeovers. Actual changeover time depends on the complexity of the box and operator familiarity, but the design prioritizes ease of adjustment to minimize downtime.
