A mid-sized fully automatic all-in-one machine offering expanded format capacity for larger carton production.
GET A QUOTE
The LYZD-2600 delivers the same intelligent digital control platform with increased format handling. Operators can adjust production parameters via touchscreen without stopping, while the order memory function enables rapid 3–5 minute job switching. Its robust design ensures precise gluing and high-speed stapling, effectively overcoming common technical challenges in larger-format box production.
Note: Special specifications can be customized according to customer’s needs.
| LYZD-2600 Gluing Mode | |
| Model | LYZD-2600 |
| Max. Paperboard Size | 1200*2600mm |
| Min. Paperboard Size | 170*420mm |
| Min. A | 130mm |
| Max. A | 850mm |
| Min. B | 40mm |
| Max. B | 450mm |
| Min. C+D+C | 170mm |
| Max. C+D+C | 1200mm |
| Min. （A+B）*2+E | 440mm |
| Max. （A+B）*2+E | 2600mm |
| Max. Mechanical Speed | 180/min |
| LYZD-2600 Stapling Mode Parameters | |||
| Max. Size of (A+B)*2 | 2600mm | Min. Length of A | 250 mm |
| Min. Size of (A+B)*2 | 800mm | Max. Height of D | 700 mm |
| Min. height of D | 150 mm | ||
| Min. Size of (C+D+C) | 300mm | Max. Nailing Tongue Width of E | 40 mm |
| Min. Size of C | 100mm | Max. Paper Feeding Height | 1200mm |
| Max. Size of C | 300 mm | Max. Length of A | 850 mm |
| Max. Width of B | 450 mm | Min. Width of B | 170mm |
| Mechanical Speed (nails/min) | 800 | Nails Quantity | 1-99 |
| NO. | Name | Picture | Brand |
|---|---|---|---|
| 1 | Machine head | Eura, China | |
| 2 | Paper feeding servo motor | Eura, China | |
| 3 | Folding | Eura, China | |
| 4 | Contactors, Circuit breakers | Schneider, France | |
| 5 | Machine head reducer | LIMING, Taiwan | |
| 6 | Intermediate relay | Schneider, France | |
| 7 | Touch screen | WEINVIEW, Taiwan | |
| 8 | Machine head | Imported Japanese mold steel | |
| 9 | Blade / Bottom mold | Alloy tungsten steel fabrication-Corrosion resistance | |
| 10 | Bearings | NSK, Japan | |
| 11 | Walking motor | GPG, Taiwan |
A1: Gluing mode runs at 170 m/min (100-450 pcs/min), while stapling mode runs at 80 m/min (40-70 pcs/min). The stapling head operates at a mechanical speed of 800 nails/min with adjustable spacing of 30-120mm.
A2: In gluing mode, it handles paperboard up to 1200×2600mm with a max perimeter of 2600mm; in stapling mode, it handles boxes up to 700mm in height with a max perimeter of 2600mm.
A3: The intelligent digital control system with order memory function enables rapid job switching in just 3–5 minutes, minimizing downtime for mixed production runs.
